Availability

We have limited stock of this item. Please contact us before ordering in quantity.

Information

Product Code HW-AX1

Tags

ALIX, ALIX 1, Linux, Mini ITX, Single board computer, Voyage

Includes

Board and case

Notes

To have an operating system installed, you will need to include an appropriately sized Compact Flash card in your order
miniPCI wireless cards do not include a pigtail or antenna

Completely fanless, quiet and cool, the ALIX 1 is ideal for use as a thin client, in kiosks, as an industrial user interface, and in wireless routers and other special purpose network devices.

The extra power and memory of the ALIX 1 means that it’s capable of running graphical environments, including Linux, BSD and Windows XP.

The ALIX 1 includes a board and case, ready for you to add your choice of Compact Flash card, operating system, expansion cards, pigtail, antenna, power supply and DIN rail clips.

Performance	500 MHz AMD Geode LX800 CPU, 256 MB RAM
Storage	Compact Flash card or Microdrive and 2.5" HDD
Power	12V DC external power supply (2.5mm internal)
Power consumption	Uses about 5W at 12V DC (excluding miniPCI cards)
Interface	GPIO, battery-backed real-time clock (RTC), buzzer
Connectivity	1 ethernet channel (10/100 Via VT6105M, supports 802.1 VLAN tagging), 1 miniPCI slot, 1 PCI slot, 2 serial (RS232) ports (console/on-board), 1 VGA port, keyboard and mouse ports, audio out and microphone ports, 2.5" IDE connector, 4 USB (2 ports/2 headers), LPT header
Size	182W x 178D x 35H (mm)
Weight	620g
Punchouts	D cutout to suit SMA
Case colours	Powdercoated black
Manufacturer	PC Engines (board) / Yawarra (case)
Model	ALIX.1D
Compliance	C-tick labelled for use in Australia; RoHS compliant (lead-free);
